TK-103 VEHICLE GSM/GPRS/GPS TRACKER AND IMMOBILIZER (ANTI CARJACK DEVICE)
Specification:
Content Specs.
Dim. 85mmx 63mmx 25mm(3.3 *2.5 *0.98 )
Weight 160g
Network GSM/GPRS/GPS
Band 850/1800/1900Mhz or 900/1800/1900Mhz or 850/900/1800/1900
GPS chip SIRF3 chip
GSM/GPRS
module Simcom300 or Simcom340
GPS sensitivity -159dBm
GPS accuracy 5m
Time To First Fix
Cold status 45s
Warm status 35s
Hot status 1s
Work voltage 10V 36V
Battery Chargeable changeable 3.7V1500mAh Li-ion battery
Standby 48hours
Storage Temp. -40 C to +85 C
Operation Temp. -20 C to +55 C
Humidity 5%--95%non-condensing
function:
TRACK VEHICLE LOCATION
TWO INDEPENDENT SMS ACTIVE SWITCH
SOS BUTTON SENDING HELP, SPEED, COORDINATES VIA SMS
OVER SPEED ALERT VIA SMS
GEO FENCE ACTIVE
TRACK WITH ONLINE GPS TRACKING SOFTWARE
MAIN POWER CUT ALERT VIA SMS
LOW BATT ALERT VIA SMS
GOOGLE MAP, EARTH SUPPORT
ANY MOBILE PHONE CAN DO CONTROL AND TRACK
IMMOBILIZE ENGINE VIA SMS
Application:
Global positioning
Real-time monitoring
Vehicle locating
Timing tracking
Cutting off power and circuit by remote control
Vehicle rental / Fleet management etc
Summary function:
Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or GPRS.
1.1 Positioning and Tracking: Through the on-line Positioning Platform or the cell phone to locates at times, and get the working status. You can choose the Positioning Platform by yourself.
1.2 Triggering Emergency Alarm: When there is a emergency happened on the vehicle, you can put on the button and the installed unit will send out alarm to the authorized numbers.
1.3 Remote controlling oil and circuit: you can control the oil and circuit via the unit by SMS in anywhere and anytime.
1.4 Remote Monitoring: In anywhere and anytime, call the phone number in the unit, when it connects, you can monitor the sound around 5 meter.
1.5 Movement Alert: Send SMS to the unit to start the movement alert function. When the vehicle is moving, the unit will send the movement alert to all authorized numbers.
1.6 Overspeed Alert: Send SMS to the unit to start the movement alert function. When the vehicle is overspeed, the unit will send the overspeed alert to all authorized numbers.
1.7 Geo-fence: Set up a geo-fence for the unit to restrict its movements within a district. The unit will send the message to all authorized numbers when it breaches the district.
1.8 the unit: send SMS to resume the default of unit.
1.9 Auto Track: You can set up auto track by SMS or on-line positioning platform.
1.10 Mileage statistics; ACC checking; cutting off power and alarm.
1.11 Compatible with the original anti-theft alarm: It will send SMS alarm after the original anti-theft alarm warning.
1.12 Modify the IP and Port of Communication Protocol for different on-line positioning platform

THIS GPS AND IMMOBILIZER SYSTEM IS VERY EASY TO USE, COMPATIBLE TO ALL AVAILABLE SIM CARD MODULES, EASY TO CONTROL VIA MOBILE PHONES BY CALLING OR SENDING SMS TO THETRACKING DEVICE OF YOUR DESIRED FUNCTION THAT IS RECOGNIZED BY THIS GADGET!
THIS GADGET HAS ALSO TWO INDEPENDENT SWITCH THAT IS CONTROLED BY SMS TO BE DRIVEN BY THE RELAY, THE BUILT IN SMS ACTIVATED SWITCH WILL SERVE YOU TO CONTROL ALL DEVICES YOU WANT, ONE OF THIS WILL BE YOUR IGNITION OR ECU, CDI MODULE TO KILL YOUR ENGINE REMOTELY ONCE THE CARJACKERS TAKES YOUR VEHICLE, BY SIMPLY SENDING TXT TO YOUR CAR IT WILL IMMOBILIZE AND YOU CAN GET EXACT COORDINATES TO BE TRACK BY ANY GOOGLE MAP OR EARTH ON YOUR PHONE OR PC!
THIS GADGET ALSO SUPPORTS SPY AUDIO MONITORING FROM YOUR CAR TO LISTEN ANY CONVERSATION WITHIN RANGE FROM YOUR CAR, VIA PHONE CALL SET AS (MONITOR MODE)....
for all vehicle owners who wants to avail this gps gadget we can assist you with the installation of the system design you prefer by giving you special wiring guide if you request.....
NOTE: WE DO NOT INSTALL THIS GADGET, WE ARE ONLY RESELLERS OF THIS ITEM, BUT SINCE WERE ALSO PROFESSIONAL AND EXPERIENCED ELECTRONIC TECH, WE CAN GIVE YOU INSTALLATION GUIDE!
BOX CONTENTS:
1PC. USER MANUAL
1PC. USER CD GUIDE
1PC. GPS ANTENNA MAGNETIC MOUNT
1PC. GSM ANTENNA
1PC. WIRING CONNECTOR
1PC. RELAY WITH CONNECTOR
1PC. SOS BUTTON
1PC. MICROPHONE
1PC. SIM CARD HOLDER
1PC. MAIN UNIT GPS MODULE WITH BUILT IN BATTERY
USER MANUAL: http://www.gpstracking.co.in/documents/TK103.pdf
http://www.gpstracking.co.in/documents/TK103.pdf
NOTE: FOR DIY INSTALLATION WE SUGGEST TO PLACE THE UNIT IN A DRY DUST FREE AREA TO PREVENT POSSIBLE DAMAGE TO MODULE, PLACE THE MODULE TO ANY UNACCESSIBLE PLACE; BEHIND DASHBOARD OR UNDER SEAT....
ALSO COMPATIBLE TO MOTORCYCLES AND SCOOTERS WITH BIG COMPARTMENTS OR IN A PLACE THAT IS NOT PRONE TO WATER AND DUST THAT CANT BE EASILY ACCESSED; MODULE CASE SIZE IS SIMILAR TO AUDIO CASSETTE TAPE CASE....
PROTECT YOUR VEHICLE FROM CARJACKERS AND THIEVES!
IF YOU HAVE MOBILE PHONE WITH GOOGLE MAP; GPS TRACKING WILL BE EASILY DONE, TO FIND THE ACTUAL LATEST LOCATION OF YOUR CAR...IMMOBILIZING CAN BE ALSO DONE VIA TEXT...
WE DO ACTUAL TEST IF YOU WANT TO PURCHASE THIS ITEM TO ENSURE ALL FUNCTION WORKING AND TO TEACH YOU BASIC OPERATION FUNCTION FOR YOUR CONVINIENCE FREE!
