Instantly reboot, start or stop equipment in remote locations. Reboot servers or routers securely from your web browser. Save power. Simplify wiring. Automate your server rack. Control power over the web from anywhere. Securely access one or hundreds of DLI switches from a seamless
interface. Create user accounts with secure access to selected circuits. Eight simultaneous users are supported. Eliminate overloads, brown-outs, blown breakers and other power problems before they occur. Start devices in sequence automatically to avoid inrush current problems. Balance multi-phase power to conserve energy. Command your on the keypad or through a friendly web interface, via a BASIC program language, from a command line, or from your own appliation. User-defined hyperlinks let you customize the web pages. A free utility sends programmable email alerts.

Use the “Auto-Ping” feature to automatically monitor critical network devices, such as telecom equipment, servers and routers. If a device goes down, the power controller will automatically reboot it with no user intervention. “Locked-up” devices are brought back to life instantly. Service calls are eliminated.

• Provides safe, clean, controlled power for 208, 220, 240VAC circuits. Also works on 120VAC.
• C-13 outlets and C-19 inlets for worldwide safety and compatibility.
• Simple, reliable, plug-and-play operation. Sets up in minutes. Robust. Easy to use.
• Control routers, servers, datatcom, IT equipment - almost any device.
• Internal Real-Time-Clock with 15-year battery backup.
• Keypad for local outlet control, Ethernet remote control.
• Enable the “Auto-Ping” feature to intelligently reboot a locked-up router, server, camera. or other device automatically, even during WAN outages.
• Use scripts to automate control from remote locations. The internal web server gives you manual or automated control from anywhere in the world.• Eight individual circuits are switched with up to 15A of power. Two unswitched outlets are also provided.
• 10/100 autosensing plug-and-play Ethernet connection with static IP allows reliable connection anywhere on your LAN, WAN, or over the Internet.
• Multiple power-up recovery modes add safety and flexibility: timed, sequential on, all-off , last state, user program control, etc.
• Lowest power draw of any competitive product - 4 watts!

SPECIFICATIONS

Alert Beeper - 68dBa at 12". Programmable.
Applications - Commercial, industrial, and datacom remote power control and reboot. Indoor use only.
Circuit Breaker - Manual reset, 15A Thermal, UL
Control / Display - Reset -to-factory-default switch 2x16 Backlit LCD w/ PowerSave 5 button local control keypad
Dimensions - RETMA 1-U compliant
Outside - 1.75x4.5x17" 19" between tips of rack ears

EEPROM - 512Kb I2C Standard
Enclosure - Aluminum chassis, double grounded. No plastic. Vented 4 sides. Fanless.
Ethernet Interface - 10/100 autosensing, Static IP, TCP port selectable, 8 pin RJ-45 w/ internal FCC filtering
FCC Testing - Part 15 S/D
Humidity - 8-80% RH Operating
Input Power Socket - UL CSA C-19 Standard
Input and Outlet Rating - UL, CSA 15A, 120-240VAC
Input Frequency - 40-400Hz
Operating Temperature - -30º to 170ºF, -34º to 77ºC

Options - User • Preconfigured Wi-Fi Router.
Options - OEM • Internal TTL serial devices
Min. Order Qty. Applies • Custom labeling • Internal WiFi • External Ports
Power Supply Rating - 90-240V, AC/DC Autosensing
Outlet Specicifcation - UL/CSA C-13 Standard
Outlet Switching - 8 individually switched circuits
Password Transmission - Encrypted, base 64 Movable HTTP port for security
Power Dissipation - 4.4W Max (circuits on) Power Fail Hold-Over - 350ms minimum (all relays on)
Power-Up Modes - Last used settings, all power on or off, sequential on or run BASIC program script.

Relay Contact Spec - 20A AC 277V
Software Controls - Individual outlets on/o! , all on/off /cycle. Net settings, Web UI
Surge Protection - 580J 25,000A MOV
Size (Single-Pack Carton) 5.5x8.2x20.8"
Weight - Single bare unit 4.2 lbs Packed with typical cord 8.4lbs
