PANASONIC PT-LB90NTEA







Power supply

• 100–240 V AC, 50/60 Hz

Power consumption

• 00 W (0.9 W*¹ in standby eco mode. 20 W in normal standby mode. 23 W in normal standby mode when set to audio monitor out and with fan stopped.)

Optical system

• Dichroic mirror separation/prism synthesis system
• Panel size 0.63" (16.00 mm) diagonal, 4:3 aspect ratio
• Display method Transparent LCD panel (x 3, R/G/B)
• Drive method Active matrix
• Pixels 786,432 (1,024 x 768) x 3, total of 2,359,296 pixels
• Pixel configuration Stripe

Lens

• Manual zoom (1:1–1:1.2), manual focus, F 1.65–1.93, f 18.53–22.18 mm

Throw ratio

• 1.4 –1.7:1

Lamp

• 220 W UHM lamp

Projection size

• 33–300 inches/838–7,620 mm diagonally (4:3 aspect ratio)

Colors

• Full color (16,777,216 colors)

Brightness*²

• 3,500 lumens


Center-to-corner uniformity ratio*²

• 85%


Contrast ratio*²

• 500:1 (full on/full off)

Resolution (RGB)

• 1,024 x 768 pixels (Input signals that exceed this resolution will be converted to 1,024 x 768 pixels.)

Scanning frequency

• RGB Horizontal: 15–91 kHz, Vertical: 50–85 Hz
• YPBPR 480i (525i): fH 15.75 kHz; fv 60 Hz 576i (625i): fH 15.63 kHz; fv 50 Hz 480p (525p): fH 31.50 kHz; fv 60 Hz 576p (625p): fH 31.25 kHz; fv 50 Hz 720/60p (750p): fH 45.00 kHz; fv 60 Hz 720/50p (750p): fH 37.50 kHz; fv 50 Hz 1080/60i (1125i): fH 33.75 kHz; fv 60 Hz 1080/50i (1125i): fH 28.13 kHz; fv 50 Hz
• S-Video / Video NTSC, NTSC4.43, PAL-M, PAL60: fH15.75 kHz; fv 60 Hz PAL, SECAM, PAL-N: fH15.63 kHz; fv 50 Hz

Optical axis shift

• 5:1 (fixed)

Keystone correction range

• Vertical: approx. ±30°

On-screen menu

• 17 languages: English, French, German, Spanish, Italian, Korean, Russian, Chinese, Japanese, Swedish, Norwegian, Danish, Portuguese, Polish, Hungarian, Czech, and Thai

Installation

• Front/rear, ceiling/desk (menu selection)

Built-in speakers

• Size: 4 x 2 cm x 1, oval Output power: 1.0 W (monaural)

Terminals

COMPUTER (RGB) 1 IN

• D-sub HD 15-pin (female) x 1
  RGB signal:
  G: 0.7 V [p-p] (1.0 V [p-p] for sync on green signals), 75 ohms, R, B: 0.7 V [p-p], 75 ohms, HD/SYNC, VD: TTL (positive/negative polarity compatible)
  YPBPR signal:
  Y: 1.0 V [p-p] (including sync signal), 75 ohms, PB, PR: 0.7 V [p-p], 75 ohms

COMPUTER (RGB) 2 IN

• D-sub HD 15-pin (female) x 1
  RGB signal:
  G: 0.7 V [p-p] (1.0 V [p-p] for sync on green signals), 75 ohms, R, B: 0.7 V [p-p], 75 ohms, HD/SYNC, VD: TTL (positive/negative polarity compatible)
  YPBPR signal:
  Y: 1.0 V [p-p] (including sync signal), 75 ohms, PB, PR: 0.7 V [p-p], 75 ohms

VIDEO IN

• RCA pin x 1, 1.0 V [p-p], 75 ohms

S-VIDEO IN

• Mini DIN 4-pin x 1, Y: 1.0 V [p-p], C: 0.286 V [p-p], 75 ohms

COMPUTER (RGB) 1/2 AUDIO IN

• M3 (L, R) x 1, 0.5 V [rms]

VIDEO / S-VIDEO AUDIO IN

• RCA (L, R) x 1, 0.5 V [rms]

VARIABLE AUDIO OUT

• M3 (L, R) x 1, 0 –2.0 V [rms]

SERIAL

• D-sub 9-pin x 1, for external control (RS-232C compliant)

LAN

• RJ-45 x 1, compatible with PJLink™ (class 1), 10BASE-T/100BASE-TX

Power cord length 2 m (6.6')

Cabinet material Molded plastic (PC+ABS)

Dimensions (W x H x D) 368 x 88 x 233 mm (14-1/2" x 3-15/32" x 9-3/16")*³

Weight*^{4 Approx. 2.96 kg (6.5 lbs.)}

Operating environment Temperature: 0°–40°C (32°–104°F) Humidity: 20%–80% (no condensation)

Wireless LAN

Standard

• IEEE 802.11b/g (ARIB STD-T66)

Modulation

• IEEE 802.11b: Direct sequence spread spectrum (DS-SS) system
• IEEE 802.11g: Orthogonal frequency division multiplex (OFDM) system

Transmission system

• IEEE 802.11b: CCK (11/5.5 Mbps), DQPSK (2 Mbps), DBPSK (1 Mbps)
• IEEE 802.11g: 64-QAM (54/48 Mbps), 16-QAM (36/24 Mbps), QPSK (18/12 Mbps), BPSK (9/6 Mbps)

Transmission speed

• EEE 802.11b: 11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps
• IEEE 802.11g: 54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6 Mbps

Operating range*⁵

• Approx. 30 m (98'5")

Frequency range

• PT-LB90NTE/LB90NTEA: 2,412 MHz–2,472 MHz
• PT-LB90NTU: 2,412 MHz–2,462 MHz

Channels

• PT-LB90NTE/LB90NTEA: 1–13 ch
• PT-LB90NTU: 1–11 ch

Supplied accessories

• Power cord
• Power cord secure lock
• Wireless remote control
• Batteries for remote control (AA type for North/South America, R6/LR6 type for Europe/Asia) x 2
• VGA cable for RGB signals (1.8 m/5'11")
• Wireless Manager ME 5.5 (CD-ROM)

*1:	In standby eco mode, network functions such as Standby On via LAN are not available, and only certain commands can be received from RS-232C control.
*2:	Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*3:	Protruding parts not included.
*4:	Average value. May differ depending on models.
*5:	Operation range differs depending on environments.

(PT-LB90NT) To use network functions, a PC is required that meets the conditions given below:

OS:	Microsoft Windows® 2000 Professional SP4 / XP Professional / XP Home Edition / XP Tablet PC Edition 2005 / Vista® Ultimate 64bit / Vista® Ultimate 32bit / Vista® Business 64bit / Vista® Business 32bit / Vista®Home Premium 64bit / Vista® Home Premium 32bit / Vista® Home Basic 64bit / Vista® Home Basic 32bit / 7 Ultimate 64bit / 7 Ultimate 32bit / 7 Professional 64bit / 7 Professional 32bit / 7 Home Premium 64bit / 7 Home Premium 32bit  Apple Mac OS X Ver10.4 / Ver10.5 / Ver10.6* * Operation is guaranteed only with preinstalled or clean-installed operating systems.
Web browser:	Windows®: Internet Explorer® 6.0 / 7.0 / 8.0 Macintosh: Safari 2.0 / 3.0 / 4.0
CPU:	Windows®: Intel® Pentium® III or higher, or other compatible processor (1 GHz or higher is recommended.) Mac OS X : 1 GHz or higher Power PC G4, or 1.8 GHz or higher Intel® Core™ Processor
Memory:	256 MB or more (512 MB or higher is recommended for Mac OS X)
Free hard disk space:	60 MB or more
CD-ROM drive:	CD-ROM drive or DVD drive
Wireless LAN:	IEEE 802.11b/g compatible (built-in wireless LAN system or external IEEE 802.11b/g LAN card must be installed and running normally.) NOTE: Some IEEE 802.11g/b wireless LAN may not allow connection to the projector. For Mac OS, Built-in IEEE 802.11b/g wireless LAN adapter must be installed and running normally.

NOTES ON USE

•	The projector uses a high-voltage mercury lamp that contains high internal pressure. This lamp may break, emitting a large sound, or fail to illuminate, due to impact or extended use. The length of time that it takes for the lamp to break or fail to illuminate varies greatly depending on individual lamp characteristics and usage conditions.
•	The brightness of the lamp will gradually decrease with use.
•	The projector includes consumable parts. The frequency of replacement for the lamp and other consumable parts will increase if the projector is subjected to extended, continuous use. For details, please consult a service representative.



WARRANTY

• 2 Years unit warranty except for glass parts.
• 2 Years labor warranty brougth-in service.
• 500 Hours or 90 Days whichever comes first for lamp.

NOW FOR ONLY

P75,000.00

Bundle with free carrying bag and

free delivery within metro manila areas.

T

 TERMS AND CONDITIONS (PLEASE READ CAREFULLY)

1. Fax or email purchse order (P.O.) and attention to Mr. Adalid with your signature.
2. No P.O. no purchase policy.
3. Cash on delivery (C.O.D.).
4. Check payment accepted. Delivery after 3 banking days clearing (excluding holiday and weekends).
5. For cash and check deposit payment please fax your deposit slip together with your confirmed P.O.
6. For cash and check deposit payments and down payments please call for bank details
7. Upon P.O. confirmation payment deposit. We will fax or email your copy of Official Invocie and O.R.
8. We don't accept credit cards.
9. We don't offer terms.
10. If stock is available in our office delivery immediately upon P.O. confirmation.
11. If stock is not available in our office next day delivery.
12. For same day delivery P.O. confirmation cut off time is 11am.
13. For next day delivery P.O. confirmation cut off time is 2pm.
14. For products that are order basis 35-45 days delivery period upon P.O. confiramtion and 50% cash or check deposit of the total amount product purchase and 50% full cash payment upon delivery.
15. For order basis products strickly NO RETURN NO EXCHANGE POLICY.
16. All products purchase is delivery within metro manila areas.
17. For provincial purchase, delivery and logistic fees will be shoulder by the client.
18. Price is subject to change without prior notice.
