Panasonic PT-LB90EA 3LCD Projector
Versatile Performance with Eco in Mind
- 3500lm, Portable LCD Projector
- Dust-resistant structure minimises image degration
- Daylight View 4 offers clear, crisp images even in bright surroundings
- Low power consumption is only 0.9 W - reduce environmental impact
- Compact, lightweight body (approximately 2.96 kg (6.5 lbs))
Bright, Easy-to-Use, Dust-Resistant
Portable Projectors
The Panasonic LB90 Series is designed for people who want a projector with excellent basic performance and ease of use—in
both portable and ceiling-mounted applications. This versatile series ensures solid performance with a dust-resistant structure, which
minimises any dust-related image degradation, and a low standby power consumption of 0.9 W*1
to reduce environmental impact.
The PT-LB90NTEA also features a network function that allows wireless/wired LAN configurations. Connecting the projector
to a wireless LAN system further boosts the layout flexibility during presentations. Wired LAN connection enables remote operation, which is especially ideal for ceiling-mounted use. Multi Projector Monitoring and Control Software, which lets you monitor and control several Panasonic projectors from a single computer, is also available. The compact body of the LB90 Series is filled with Panasonic
projector technologies to meet needs of many kinds.
Dust-Resistant Structure Minimises
Image Degradation
After a projector has been used for some time, dust particles that have entered the
interior accumulate on the optical components and lower their performance. The LB90 Series prevents this with a unique
dust-resistant structure. The LB90 Series has touch-sensor controls that eliminate
the gaps around conventional buttons, and a lens cover. The design also incorporates a cover that protects the zoom/focus ring when not in use. These features combine to help reduce dust entry. And they all work together with the high-performance Micro
Cut Filter, which effectively traps dust particles, to minimise brightness degradation.
Daylight View 4 Offers Clear, Crisp
Images Even in Bright Surroundings*
2 Daylight View 4 measures the surrounding illumination with a built-in ambient light sensor, and corrects the image in real-time to project clear, crisp images even in brightly lit rooms. It improves perceived sharpness, brightness and contrast, and projects lifelike images
with remarkable depth.
Low Standby Power Consumption of
0.9 W*
1 The ecological design of the LB90 Series greatly reduces its environmental impact. In Eco Standby mode, power consumption is
only 0.9 W*1.
This reduction brings standby power consumption down to about 1/3 the level of previous Panasonic models*3.
As examples of other environmental design features, no halogenated flame retardants are used in the cabinet, lead-free glass is
used for the lens, and an Auto Off Timer switches the projector to Standby mode when no input signal is received for a preset time. The LB90 Series also complies with the standards of the RoHS Directive*4.
E c o I n f o r m a t i o n
• No halogenated flame retardants are used in the cabinet.
• Lead-free glass is used for the lens.
• An Auto Off Timer switches the projector to Standby mode when no input
Wired/Wireless LAN Compatible Network Functions
(Only on the PT-LB90NTEA)
Quick and Easy Set-Up for Flexible
Presentations
The Wireless Manager ME5.5 application that is included with the projector makes it easy to send and display a computer screen
when the PC and projector are connected to a wired or wireless* 5LAN system. You can also send audio*6 and video* 7 files. The
application is compatible with both Windows® and Macintosh, and can be used with a wide range of computers. Wireless Manager ME 5.5 operation can be controlled with the launcher that is displayed on the PC screen. Its graphic display further simplifies operation. When connected to a wireless LAN* 5system, you don’t need to connect a VGA cable to the PC, so set-up is quick and easy, and the layout is highly flexible. You can also project several PC screens, so meetings with a large numbe
| LCD panel | |
| Panel size | 0.63" (16 mm) diagonal, 4:3 aspect ratio, MLA |
| Display method | Transparent LCD panel (x 3, R/G/B) |
| Drive method | Active matrix |
| Pixels | 786,432 (1,024 x 768) x 3 |
| Lens | Manual zoom (1:1-1:1.2), manual focus, F 1.65–1.93, f 18.53–22.18 mm |
| Throw ratio | 1.4 -1.7:1 |
| Lamp | 220 W UHM™ lamp |
| Projection size (diagonally) | 33-300 inches (4:3 aspect ratio) |
| Colours | Full colour (16,777,216 colours) |
| Brightness* 1 | 3,500 lumens |
| Centre-to-corner uniformity* 1 | 85 % |
| Contrast ratio* 1 | 500:1 (full on /full off) |
| Resolution (RGB) | 1,024 x 768*2 |
| Scanning frequency | |
| RGB | Horizontal: 15-91 kHz, Vertical: 50-85 Hz |
| YPBPR | 480i (525i): fH 15.75 kHz; fV 60 Hz 480p (525p): fH 31.5 kHz; fV 50 Hz 576i (625i): fH 15.63 kHz; fV 60 Hz 576p (625p): fH 31.25 kHz; fV 50 Hz 720p (750p): fH 45.00 kHz; fV 60 Hz 720p (750p): fH 37.50 kHz; fV 50 Hz 1080i (1125i): fH 33.75 kHz; fV 60 Hz 1080i (1125i): fH 28.13 kHz; fV 50 Hz |
| S-Video/Video | NTSC, NTSC4.43, PAL-M, PAL60: fH 15.75 kHz; fV 60 Hz PAL, SECAM, PAL-N: fH 15.63 kHz; fV 50 Hz |
| Optical axis shift | 5:1 (fixed) |
| Keystone correction range | Vertical: ±30° |
| On-screen menu | 17 languages: English, French, German, Spanish, Italian, Korean, Russian, Chinese, Japanese, Swedish, Norwegian, Danish, Portuguese, Polish, Hungarian, Czech, and Thai |
| Installation | Front/rear ceiling/desk (menu selection) |
| Built-in speakers | 1.0 W (monaural) output power |
| Terminals | |
| COMPUTER 1 IN | D-sub HD 15-pin x 1 |
| COMPUTER 2 IN/1 OUT | D-sub HD 15-pin x 1 (input/output selectable using on-screen menu) |
| VIDEO IN | RCA pin x 1 |
| S-VIDEO IN | Mini DIN 4-pin x 1 |
| AUDIO IN | RCA (L-R) x 1 (for VIDEO/S-VIDEO) |
| COMPUTER AUDIO IN | M3 (stereo) x 1 |
| VARIABLE AUDIO OUT | M3 (stereo) x 1 |
| SERIAL | D-sub 9-pin x 1 (RS-232C) |
| Power cord length | 2 m (6&7") |
| Cabinet material | Moulded plastic (PC+ABS) |
| Dimensions* 4 (W x H x D) | 368 x 88 x 233 mm (14-1/2" x 3-15/32" x 9-3/16") |
| Weight | 2.96 kg (6.5 lbs.) |
| Operation environment | |
| Temperature | 0°-40°C (32°-104°F) |
| Humidity | 20%-80% (no condensation) |
| Wireless LAN | |
| Standard | - |
| Operation range* 5 | - |
| Infrastructure mode | - |
| Ad-hoc mode | - |
| Wireless remote control unit | |
| Power supply | 3 V DC (AA battery x 2) |
| Operation range* 5 | Approx. 15 m (49&3" feet) when operated from directly in front of the signal receptor |
| Dimensions (W x H x D) | 48 x 163 x 24.5 mm (1-7/8" x 6-13/32" x 31/32") |
| Weight | 117 g (4.2 oz) (including batteries) |
| Supplied accessories | Power cord, power cord secure lock, wireless remote control, batteries for remote control, VGA cable, carrying bag |
WARRANTY
- 2 Years unit warranty except for glass parts.
- 2 Years labor warranty brought-in service.
- 500 Hours or 90 Days whichever comes first for lamp.
NOW FOR ONLY
P79,000.00
Bundle with free carrying bag and
free delivery within metro manila areas.
TERMS AND CONDITIONS (PLEASE READ CAREFULLY)
- Fax or email purchse order (P.O.) and attention to Mr. Adalid with your signature.
- No P.O. no purchase policy.
- Cash on delivery (C.O.D.).
- Check payment accepted. Delivery after 3 banking days clearing (excluding holiday and weekends).
- For cash and check deposit payment please fax your deposit slip together with your confirmed P.O.
- For cash and check deposit payments and down payments please call for bank details
- Upon P.O. confirmation payment deposit. We will fax or email your copy of Official Invocie and O.R.
- We don't accept credit cards.
- We don't offer terms.
- If stock is available in our office delivery immediately upon P.O. confirmation.
- If stock is not available in our office next day delivery.
- For same day delivery P.O. confirmation cut off time is 11am.
- For next day delivery P.O. confirmation cut off time is 2pm.
- For products that are order basis 35-45 days delivery period upon P.O. confiramtion and 50% cash or check deposit of the total amount product purchase and 50% full cash payment upon delivery.
- For order basis products strickly NO RETURN NO EXCHANGE POLICY.
- All products purchase is delivery within metro manila areas.
- For provincial purchase, delivery and logistic fees will be shoulder by the client.
- Price is subject to change without prior notice.
