PANASONIC PT-DX800

1-chip DLP Projectors

Tech : DLP, 8000 ANSI Lumens, Resolution : XGA, Weight : 16,3 kg

Crisp Pictures with 8,000 lm for Effective Visual Communication
If you are looking for a compact but powerful projector, check out the Panasonic PT-DX800 Series 1-chip DLPTM projector. The PT-DX800 produce 8,000 lm of brightness, respectively. The RGB Booster ensures vivid, colourful images, and the original Eco Filter eliminates the need for filter replace- ment for up to 12,000 hours.*1 Complete with a dual-lamp system, the PT-DX800 Series gives you high reliability and hassle-free maintenance. Both models enable easy and flexible system configuration.

Bright 8000 lm from Compact Body
New lamp drive system has helped to make the body as compact as Panasonic’s original PT-DZ6700 Series,* while providing high brightness of 8,000 lm for the PT-DX800S and 7,000 lm for the PT-DW730S.

* PT-DZ6710/DZ6700/DW6300S/D6000S/D5000S.

RGB Booster Significantly Improves Color Reproduction
The RGB Booster achieves high image quality with levels of color reproduction and brightness that make each color stand out. It combines Panasonic’s proprietary Vivid Color Control technology with a newly engineered Lamp Modulation Drive System for a 1-chip DLP™ projector that produces bright and vivid colors.

Vivid Color Control
This unique control technology optimizes the use of the color segment areas of the color wheel. It increases the brightness of each RGB color by minimizing the unallocated portions between the colors, to achieve truly vivid coloring.

Lamp Modulation Drive System
With the advanced lamp modulation technology, the projector is able to control the lamp intensity for each of the red, green, blue, and white segments of the color wheel separately. Because the actual light output is controlled in relation to each color segment, light usage is optimized and color balance is obtained without lowering the brightness. This results in bright vivid images with increased color fidelity.

Detail Clarity Processor Brings Depth and Clarity to Details
This advanced image-processing circuit analyzes the video signal frequency range for each scene by extracting data on the distribution of high, mid, and low-frequency components, and brings out fine details accordingly. The resulting images have a more natural, three-dimensional appearance with crisp, clear detail.

System Daylight View 2 for Enhanced Color Perception
Image details are less clear when a projector is used in a room with the lights on. Panasonic’s System Daylight View 2 improves brightness perception by adjusting sharpness, gamma curves, and color corrections. This produces crisper, more stunning images with vivid colors even under bright conditions.

Flexible Installation
The wide adjustment range of the powered horizontal/vertical lens shift function assures convenience and versatility during installation. It lets you easily make adjustments with the remote control. The unit can also be rotated 360 degrees vertically. This means you can install it at any angle you want, to accommodate different installation conditions.

A Wide Range of Optional Lenses
Choose from a wide lineup of optional lenses for your system, including short-throw, long-throw zoom and fixed-throw lenses for rear projection use. The additional lenses make it easy to adapt your projector to the installation site. The lenses attach and detach with one-touch ease.

Model		PT-DW730S	PT-DX800S
Power supply	PT-DW730US/ DX800US (North America)	120 V AC, 7.5 A, 50/60 Hz
	PT-DW730ES/ DX800ES (Europe and Asia)	220-240 V AC, 4.3 A, 50/60 Hz
Power consumption	PT-DW730US/ DX800US (North America)	790 W (830 VA) at 120 V AC (0.2 W at 120 V AC when standby mode set to eco*1,  8 W at 120 V AC when standby mode set to normal. Both with fan stopped.)
	PT-DW730ES/ DX800ES (Europe and Asia)	760 W (950 VA) at 240 V AC (0.3 W at 220-240 V AC when standby mode set to eco*1, 9 W at 220-240 V AC when standby mode set to normal. Both with fan stopped.)
DLP™ chip	Panel size	16.5 mm (0.65 inches) diagonal  (16:10 aspect ratio)	17.8 mm (0.7 inches) diagonal  (4:3 aspect ratio)
	Display method	DLP™ chip × 1, DLP™ projection system
	Pixels	1,024,000 (1,280 × 800) pixels	786,432 (1,024 × 768) pixels
Lens	PT-DW730S/ DX800S	Powered zoom (throw ratio 1.8 – 2.5:1), powered focus F 1.7–1.9, f 25.6 – 35.7 mm
	PT-DW730LS/ DX800LS	Optional powered zoom/focus lenses and fixed-focus lens
Lamp		300 W (max. 310 W) UHM lamp × 2
Screen size (diagonal)		1.27 – 15.24 m (50 – 600 inches),  1.27 – 5.08 m (50 – 200 inches) with  the ET-DLE055, 16:10 aspect ratio	1.27 – 15.24 m (50 – 600 inches),  1.27 – 5.08 m (50 – 200 inches) with  the ET-DLE055, 4:3 aspect ratio
Brightness*2		7,000 lm (dual-lamp, lamp mode: high)	8,000 lm (dual-lamp, lamp mode: high)
Center-to-corner uniformity*2		90 %
Contrast*2		2,500:1 (full on/full off, contrast mode: high*3)	2,000:1 (full on/full off, contrast mode: high*3)
Resolution		1,280 × 800 pixels (Input signals that  exceed this resolution will be  converted to 1,280 × 800 pixels.)	1,024 × 768 pixels (Input signals that  exceed this resolution will be converted to 1,024 × 768 pixels.)
Scanning frequency	DVI-D	fH: 15 – 91 kHz, fV: 50 – 85 Hz, dot clock: 162 MHz or lower
	RGB	fH: 15 – 91 kHz, fV: 50 – 85 Hz, dot clock: 150 MHz or lower
	YPBPR(YCBCR)	fH: 15.75 kHz, fV: 60 Hz [480i (525i)] fH: 31.50 kHz, fV: 60 Hz [480p (525p)] fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p] fH: 33.75 kHz, fV: 60 Hz [1035/60i] fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i] fH: 27.00 kHz, fV: 24 Hz [1080/24p] fH: 33.75 kHz, fV: 30 Hz [1080/30p] fH: 56.25 kHz, fV: 50 Hz [1080/50p]	fH: 15.63 kHz, fV: 50 Hz [576i (625i)] fH: 31.25 kHz, fV: 50 Hz [576p (625p)] fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p] fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i] fH: 28.13 kHz, fV: 25 Hz [1080/25p] fH: 27.00 kHz, fV: 48 Hz [1080/24sF] fH: 67.50 kHz, fV: 60 Hz [1080/60p]
	Video/ S-Video	fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60], fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical  axis shift	Vertical	+60% from center of screen  (powered)	+50% (+45% with the ET-DLE080) from center of screen (powered)
	Horizontal	±10% from center of screen  (powered)	±10% from center of screen  (powered)
Keystone correction range		Vertical: ±40° (±30° with the ET-DLE055/DLE080)
Installation		Ceiling/floor, front/rear
Terminals	DVI-I D IN	DVI-D 24-pin × 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only) 480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/24sF, 1080/25p, 1080/30p,  1080/60p, 1080/50p, VGA (640 × 480) – WUXGA (1,920 × 1,200)*4,  compatible with non-interlaced signals only, dot clock: 25 – 162 MHz
	RGB 1 IN	BNC × 5 (RGB/YPBPR/YCBCR × 1)
	RGB 2 IN	D-Sub HD 15-pin (female) × 1 (RGB/YPBPR/YCBCR × 1)
	VIDEO IN	BNC × 1 (composite video)
	S-VIDEO IN	Mini DIN 4-pin × 1 (S-Video)
	SERIAL IN	D-sub 9-pin (female) × 1 for external control (RS-232C compliant)
	SERIAL OUT	D-sub 9-pin (male) × 1 for link control (RS-232C compliant)
	REMOTE 1 IN	M3 × 1 for wired remote control
	REMOTE 1 OUT	M3 × 1 for link control (for wired remote control)
	REMOTE 2 IN	D-sub 9-pin (female) × 1 for external control (parallel)
	LAN	RJ-45 × 1 (for network connection, 10Base-T/100Base-TX, compliant with PJLink™)
Cabinet materials		Molded plastic
Dimensions  (W × H × D)	PT-DW730S/ DX800S	498 × 175*5 × 466*6 mm (19-19/32? × 6-7/8? *5 × 18-11/32? *6)(with supplied lens)
	PT-DW730LS/ DX800LS	498 × 175*5 × 432*6 mm (19-19/32? × 6-7/8? *5 × 17? *6) (without lens)
Weight	PT-DW730S/ DX800S	Approximately 16.3 kg (35.9 lbs) (with supplied lens)
	PT-DW730LS/ DX800LS	Approximately 15.4 kg (34.0 lbs) (without lens)
Operating environment		Operating temperature: 0°C – 45°C (32°F – 113°F)*7,  operating humidity: 20% – 80% (no condensation)
Supplied accessories		Power cord, power cord secure lock, wireless/wired remote control unit,  batteries (R6/AA type × 2)
Warranty		2 years unit warranty except for glass parts. 2 years labor warranty brought-in service. 500 hours or 90 days whichever comes first for lamp.

*1 When the standby mode is set to eco, network functions such as power on over the LAN will not operate. Also, only certain commands can be received for external control using the serial terminal.
*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*3 Brightness : 3,500 lm for the PT-DW730S/DW730LS; 4,000 lm for the PT-DX800S/DX800LS.
*4 Compliant with VESA CVT-RB.
*5 With legs at shortest position.
*6 Protruding parts not included.
*7 The operating temperature range is 0°C to 40°C (32°F to 104°F) when the fan control is set to High Altitude mode (for altitudes from 1,400 m to 2,700 m (4,593 ft to 8,858 ft) above sea level). Also, if the ambient temperature exceeds 40°C (104°F) (35°C (95°F) in High Altitude mode) when the projector is being used with Lamp Select set to Dual and Lamp Power set to High, the light output may be reduced approximately 20% to protect the projector.

 FOR ONLY

P408,000.00

FREE DELIVBERY WITHIN METRO MANILA AREAS

LIMITED STOCKS ONLY



 TERMS AND CONDITIONS (PLEASE READ CAREFULLY)



1. Fax or email purchse order (P.O.) and attention to Mr. Adalid with your signature.
2. No P.O. no purchase policy.
3. Cash on delivery (C.O.D.).
4. Check payment accepted. Delivery after 3 banking days clearing (excluding holiday and weekends).
5. For cash and check deposit payment please fax your deposit slip together with your confirmed P.O.
6. For cash and check deposit payments and down payments please call for bank details
7. Upon P.O. confirmation payment deposit. We will fax or email your copy of Official Invocie and O.R.
8. We don't accept credit cards.
9. We don't offer terms.
10. If stock is available in our office delivery immediately upon P.O. confirmation.
11. If stock is not available in our office next day delivery.
12. For same day delivery P.O. confirmation cut off time is 11am.
13. For next day delivery P.O. confirmation cut off time is 2pm.
14. For products that are order basis 35-45 days delivery period upon P.O. confiramtion and 50% cash or check deposit of the total amount product purchase and 50% full cash payment upon delivery.
15. For order basis products strickly NO RETURN NO EXCHANGE POLICY.
16. All products purchase is delivery within metro manila areas.
17. For provincial purchase, delivery and logistic fees will be shoulder by the client.
18. Price is subject to change without prior notice.

FOR INQUIRIES AND ORDER PLACEMENT PLEASE CONTACT
