THE NEW HOME THEATER

PANASONIC PT-AR100E

(LIMITED STOCKS)

KEY FEATURES

• Full-HD LCD projection
• 2,800 lumens of brightness
• 50,000:1 contrast ratio
• 7 picture modes
• Simple installation

Full-HD versatile home projector with 2,800 lumens of brightness

The beauty of a Full-HD home projector is home entertainment on a large-scale, with a true cinematic experience. The PT-AR100 Full-HD LCD projector offers 1080p (1,920 x 1,080 pixel) resolution and a wide range of Panasonic imaging technologies, so your friends and family enjoy everything from movies and sports to video games, with stunning clarity in a large-screen format.

Bright, sharp images in any lighting condition

By combining an advanced optical unit and a new 280-W Red-Rich lamp, the PT-AR100 is able to generate an amazing 2,800 lumens of brightness. Assisted by Panasonic’s Light Harmonizer 3 technology, this projector can then automatically adjust the picture quality of the image to match the living room or theatre, allowing for comfortable viewing across a range of lighting conditions. Built-in ambient light and colour sensors also work to constantly maintain bright, crisp pictures that match the viewing environment.

High contrast equals deeper blacks and brighter colour

An astounding contrast ratio of 50,000:1 provides a wide dynamic range to enhance the beauty in both dark and bright scenes. Panasonic technologies such as the Dynamic Iris Pro and Pure Colour Filter Pro combine to achieve a high purity level of the three primary colours—red, green and blue—while displaying deeper blacks, for a more natural colour appearance. In addition, the PT-AR100 excels at showing fine detail thanks to the Detail Clarity Processor 3 engine.

The right picture mode for all your favourite content

Seven different picture modes provide optimal performance for different content, including the highly important Cinema, Sport and Game modes. Movies can be enjoyed in Cinema 1 mode that has been tuned carefully to faithfully express the director’s artistic intent. Panasonic has continued to work with Hollywood experts to deliver this ideal image reproduction for viewing movies. Game mode improves signal processing for better response time and also reveals gradation in saturated areas to show details that are otherwise lost in very dark areas. In Sports mode, together with the Motion Effect feature, the PT-AR100 improves detail on moving objects, resulting in intensified action.

Easy to set up and use

The 2x optical zoom lens provides a wide throw range and the projector’s lens shift capability enables 65 percent vertical adjustment and 26 percent horizontal adjustment. What this means in real terms is that the PT-AR100 functions beautifully in a variety of different-rooms, from a small sized media room to a mini cinema. This outstanding set-up flexibility allows you to position the projector in the most convenient place, such as a shelf in front of or behind the seating area, or even suspended from the ceiling. The PT-AR100 is also equipped with two HDMI inputs, so multiple HD sources can be connected without an HDMI switcher. Automation, such as lighting and a motorised screen, is possible with the PT-AR100 because it comes equipped with two programmable 12-volt trigger terminals and VIERA Link.

Large screen group entertainment

Installation flexibility and ease of use

Superb picture quality

Specifications

PANEL
Panel Type	LCD
Panel Size - Diagonal (mm)	18.7 (16:9 aspect ratio)
Display Method	Transparent LCD Panel (x 3, R / G / B)
Drive Method	Active Matrix
Pixels	2,073,600 (1920 x 1080) x 3 Total of 6,220,800
Pixel Configuration	-

DISPLAY
	-
Lens	Manual Zoom 1.33 – 2.69:1 Manual Focus Lenses F 2.0 – 3.4, f 21.5 – 43.0 mm
Throw Ratio	1.16 - 18.08
Lamp (W)	280 UHM Lamp
Screen Size - Diagonal (m)	1.02 - 7.62
Colours	Full Colour (1,073,741,824 colours)
Brightness (lumens)	2800
Center-to-corner Uniformity (%)	85
Contrast Ratio	50,000:1
Resolution (pixels)	1920 × 1080

SCANNING FREQUENCY
SD-SDI	-
HD-SDI	-
Dual-link HD-SDI	-
3G-SDI	-
HDMI / DVI-D	-
RGB	f H : 15 – 74 kHz, f V : 24 – 85 Hz, Dot clock: 154 MHz or lower
YP B P R (YC B C R)	525i (480i), 625i (576i), 525p (480p), 625p (576p), 750 (720)/60p, 750 (720)/50p, 1125 (1080)/60i, 1125 (1080)/50i, 1125 (1080)/24p, 1125 (1080)/60p, 1125 (1080)/50p
Video / S-Video	f H : 15.75 kHz, f V : 60 Hz [NTSC / NTSC4.43 / PAL-M / PAL60] f H : 15.63 kHz, f V : 50 Hz [PAL / PAL-N / SECAM]

OPTICAL OFFSET
Optical Axis Shift	Vertical: ±65%, Horizontal: ±26%
Keystone Correction Range	Vertical: Approx. ±30°
Keystone Correction Range with Optional Geometry Manager Pro	-
Installation	Ceiling / Desk, Front / Rear

TERMINALS
HDMI IN	HDMI connector × 2 HDMI™ (Deep Color, x.v.Color™, CEC) HDCP compliant, supports HDAVI Control Version 5
Computer 1 IN	D-sub HD 15-pin × 1 (RGB / YP B P R × 1)
Computer 2 IN	COMPONENT IN RCA pin × 3 (YPBPR / YCBCR)
Trigger IN / OUT  3D Shutter OUT	TRIGGER IN / TRIGGER OUT M3 × 2, 12 V, Max. 100 mA (input / output selectable using on-screen menu)
Video IN	RCA pin x 1
S-Video IN	Mini DIN 4-pin x 1
Serial IN	D-sub 9-pin × 1 for external control (RS-232C compliant)
Optional	Replacement Lamp Unit ET-LAA110  Ceiling Mount Bracket ET-PKA110H (for high ceilings) Ceiling Mount Bracket ET-PKA110S (for low ceilings)

POWER
Power Supply (V AC)	100 - 240 AC, 50 / 60 Hz
Power Consumption (W)	350  0.08 Standby Mode
Power Cord Length (m)	3

GENERAL
Cabinet Materials	Moulded Plastic
Dimensions - W x H x D (mm)	48 x 138 x 28.3
Weight (kg)	8.6
Operating Noise (dB)	29 (Lamp Power: Eco)
Operating Temperature (o C)	0 – 40
Operating Humidity (%)	20 – 80 (no condensation)
Filter	-
Other	-

EMOTE CONTROL UNIT
Power Supply (V)	3 DC (R6 / AA type battery) × 2
Operation Range (m)	Approx. 7 (when operated from directly in front of the signal receptor)
Dimensions - W x H x D (mm)
Weight - Including Batteries (g)	Approx. 125

ACCESSORIES
Standard	Power Cord x 1 (× 2 for PT-AR100EA) Wireless Remote Control Unit  Batteries for Remote Control × 2  Lens Cover

PANASONIC WARRANTY

• 2 YEARS UNIT WARRANTY EXECEPT FOR GLASS PARTS.
• 2 YEARS LABOR WARRANTY. BROUGHT-IN SERVICE.
• 1ST 500 HOURS OR 90 DAYS WHICHEVR COMES FIRST FOR LAMP WARRANTY.



FOR ONLY

P133,000.00

(LIMITED STOCKS ONLY)

 TERMS AND CONDITIONS (PLEASE READ CAREFULLY)

1. Fax or email purchse order (P.O.) and attention to Mr. Adalid with your signature.
2. No P.O. no purchase policy.
3. Cash on delivery (C.O.D.).
4. Check payment accepted. Delivery after 3 banking days clearing (excluding holiday and weekends).
5. For cash and check deposit payment please fax your deposit slip together with your confirmed P.O.
6. For cash and check deposit payments and down payments please call for bank details
7. Upon P.O. confirmation payment deposit. We will fax or email your copy of Official Invocie and O.R.
8. We don't accept credit cards.
9. We don't offer terms.
10. If stock is available in our office delivery immediately upon P.O. confirmation.
11. If stock is not available in our office next day delivery.
12. For same day delivery P.O. confirmation cut off time is 11am.
13. For next day delivery P.O. confirmation cut off time is 2pm.
14. For products that are order basis 35-45 days delivery period upon P.O. confiramtion and 50% cash or check deposit of the total amount product purchase and 50% full cash payment upon delivery.
15. For order basis products strickly NO RETURN NO EXCHANGE POLICY.
16. All products purchase is delivery within metro manila areas.
17. For provincial purchase, delivery and logistic fees will be shoulder by the client.
18. Price is subject to change without prior notice.
