THE ALL NEW



PANASONIC PT-AE7000E

HOME THEATER

KEY FEATURES

• Stunning FHD, 2D and 3D projection
• Rich and vibrant colours with the Pure Colour Filter
• Smooth Screen Technology for Cinema-like image quality
• New 480Hz- LCD panels for a brighter 3D image
• Overdrive technology for more comfortable 3D viewing

PT-AE7000

Enjoy the 3D quality demanded by Hollywood professionals in your own home

Developed in collaboration with engineers from the Panasonic Hollywood Laboratory, the PT-AE7000 Full-HD 3D home theatre projector has been designed to produce images that mirror movie directors’ artistic vision and intent.

Superior studio-grade 3D technology

High-speed 480Hz LCD panels give the PT-AE7000 an edge over other 3D projectors that dedicated home cinema lovers will really appreciate. Together with Panasonic’s original high-precision overdrive technology, this projector is capable of bright 3D images while minimising crosstalk, or the double-images that inferior projectors are plagued with. The PT-AE7000 is also equipped with a newly-developed dual-core processing engine to enhance fine details, and bring out the natural life-like visuals in both 3D and 2D scenes, even with fast-moving sports or action movies. In terms of creating a high-quality cinema experience at home, the PT-AE7000 has the added advantage of adjustable 3D picture balance features and the ability to convert 2D content into 3D images with five different 3D effect modes.

Glorious picture quality – in any dimension

The optical system of the PT-AE7000U features a new 200 watt Red-Rich Lamp and new LCD panels with larger aperture ratio for increased red luminance and brightness output. The combination of fully-optimized Pure Contrast Plates, Pure Colour Filter Pro and Dynamic Iris Pro has resulted in a 300,000:1 contrast ratio and 2,000 lumens of brightness, producing images with excellent colouring and deep blacks with fine shadow details.

Customise your dream theatre

The PT-AE7000 is rich with features for enthusiasts who wish to customise the perfect home theatre. The projector's Intelligent Lens Memory feature means you can easily program up to six different zoom/focus positions. Automatic switching between 16:9 and 2.35:1 video content is also possible thanks to the signal aspect detection capability on the PT-AE7000. More theatre automation, such as lighting and a motorised screen, can be achieved with the PT-AE7000 because it comes equipped with two programmable 12-volt trigger terminals. The holy grail of home cinemas is a set-up that can be operated with one device and the VIERA Link feature does this by providing seamless operation of multiple compatible Panasonic devices by using the PT-AE7000 remote control.





200W Red Rich Lamp



300,000:1 Contrast ratio

3D technology



Superior picture quality

Specifications

PANEL
Panel Type	LCD
Panel Size - Diagonal (mm)	18.7 (16:9 aspect ratio)
Display Method	Transparent LCD Panel (x 3, R / G / B)
Drive Method	Active Matrix
Pixels	2,073,600 (1920 x 1080) x 3 Total of 6,220,800

DISPLAY
	4000 (Lamp Power: Normal) 5000 (Lamp Power: Eco)
Lens	Powered Zoom / Focus Lenses 1.35:1 - 2.7:1,  F 1.9 - 3.2, f 22.4 - 44.8 mm
Throw Ratio	1.16 - 18.08
Lamp (W)	200 UHM Lamp
Screen Size - Diagonal (m)	2D Projection: 1.02 - 7.62  3D Projection: 1.02 - 5.08
Colours	Full Colour (1,073,741,824 colours)
Brightness (lumens)	2000
Center-to-corner Uniformity (%)	85
Contrast Ratio	300,000:1
Resolution (pixels)	1920 × 1080



SCANNING FREQUENCY
SD-SDI	-
HD-SDI	-
Dual-link HD-SDI	-
3G-SDI	-
HDMI / DVI-D	-
RGB	f H : 15 – 74 kHz, f V : 24 – 85 Hz, Dot clock: 154 MHz or lower
YP B P R (YC B C R)	f H : 15.75 kHz, f V : 60 Hz [525i (480i)] f H : 31.50 kHz, f V : 60 Hz [525p (480p)] f H : 45.00 kHz, f V : 60 Hz [750 (720)/60p] f H : 33.75 kHz, f V : 60 Hz [1125 (1080)/60i] f H : 27.00 kHz, f V : 24 Hz [1125 (1080)/24p] f H : 56.25 kHz, f V : 50 Hz [1125 (1080)/50p] f H : 15.63 kHz, f V : 50 Hz [625i (576i)] f H : 31.25 kHz, f V : 50 Hz [625p (576p)] f H : 37.50 kHz, f V : 50 Hz [750 (720)/50p] f H : 28.13 kHz, f V : 50 Hz [1125 (1080)/50i] f H : 67.50 kHz, f V : 60 Hz [1125 (1080)/60p]
Video / S-Video	f H : 15.75 kHz, f V : 60 Hz [NTSC / NTSC4.43 / PAL-M / PAL60] f H : 15.63 kHz, f V : 50 Hz [PAL / PAL-N / SECAM]

OPTICAL OFFSET
Optical Axis Shift	Vertical: ±100%, Horizontal: ±26%
Keystone Correction Range	Vertical: Approx. ±30°
Installation	Ceiling / Desk, Front / Rear

BUILT-IN SPEAKER
Size (cm)	-
Output Power (W)	-
TERMINALS
HDMI IN	HDMI connector × 3 HDMI™ (Deep Color, x.v.Color™, CEC),  HDCP compliant, supports HDAVI Control Version 5
Computer 1 IN	D-sub HD 15-pin × 1 (RGB / YP B P R × 1)
Computer 1 IN - RGB	R, G, B: 0.7 Vp-p (1.0 Vp-p for sync on G), 75 ohms, HD / SYNC, VD: TTL (positive / negative polarity compatible) Note: HD / SYNC, and VD terminals do not accept tri-level sync signals
Computer 1 IN - YP B P R (YC B C R)	Y: 1.0 Vp-p (including sync signal) P B /P R : 0.7 Vp-p, 75 ohms
Computer 2 IN	COMPONENT IN RCA pin × 3 (YPBPR / YCBCR)
Computer 2 IN - RGB	-
Computer 2 IN - YP B P R (YC B C R)	Y: 1.0 Vp-p, 75 ohms P B /C B , P R /C R: 0.7 Vp-p, 75 ohms
Computer (RGB) 2 IN / 1 OUT R, G, B / 5BNC / VIDEO IN	-
Trigger IN / OUT  3D Shutter OUT	M3 × 2, 12 V, Max. 100 mA (input / output / 3D shutter output selectable using on-screen menu)
Video IN	RCA pin x 1
Video OUT	-
S-Video IN	Mini DIN 4-pin x 1
Serial IN	D-sub 9-pin × 1 for external control (RS-232C compliant)
Optional	Replacement Lamp Unit ET-LAA310  Ceiling Mount Bracket ET-PKA110H (for high ceilings) Ceiling Mount Bracket ET-PKA110S (for low ceilings) 3D Eyewear TY-EW3D2L (large) , TY-EW3D2M (medium), TY-EW3D2S (small) 3D IR Transmitter ET-TRM110

POWER
Power Supply (V AC)	100 - 240 AC, 50 / 60 Hz
Power Consumption (W)	285  0.08 Standby Mode with fan stopped
Power Cord Length (m)	3
GENERAL
Cabinet Materials	Moulded Plastic
Dimensions - W x H x D (mm)	48 x 138 x 28.3
Weight (kg)	8.6999999999999993
Operating Noise (dB)	22 (Lamp Power: Eco)
Operating Temperature (o C)	0 – 40
Operating Humidity (%)	20 – 80 (no condensation)

REMOTE CONTROL UNIT
Power Supply (V)	3 DC (R6 / AA type battery) × 2
Operation Range (m)	Approx. 7 (when operated from directly in front of the signal receptor)
Dimensions - W x H x D (mm)
Weight - Including Batteries (g)	Approx. 125
ACCESSORIES
Standard	Power Cord Wireless Remote Control Unit  Batteries for Remote Control × 2  Lens Cover

PANASONIC WARRANTY

• 2 YEARS UNIT WARRANTY EXECEPT FOR GLASS PARTS.
• 2 YEARS LABOR WARRANTY. BROUGHT-IN SERVICE.
• 1ST 500 HOURS OR 90 DAYS WHICHEVR COMES FIRST FOR LAMP WARRANTY.



FOR ONLY

P183,000.00

(LIMITED STOCKS ONLY)

 TERMS AND CONDITIONS (PLEASE READ CAREFULLY)

1. Fax or email purchse order (P.O.) and attention to Mr. Adalid with your signature.
2. No P.O. no purchase policy.
3. Cash on delivery (C.O.D.).
4. Check payment accepted. Delivery after 3 banking days clearing (excluding holiday and weekends).
5. For cash and check deposit payment please fax your deposit slip together with your confirmed P.O.
6. For cash and check deposit payments and down payments please call for bank details
7. Upon P.O. confirmation payment deposit. We will fax or email your copy of Official Invocie and O.R.
8. We don't accept credit cards.
9. We don't offer terms.
10. If stock is available in our office delivery immediately upon P.O. confirmation.
11. If stock is not available in our office next day delivery.
12. For same day delivery P.O. confirmation cut off time is 11am.
13. For next day delivery P.O. confirmation cut off time is 2pm.
14. For products that are order basis 35-45 days delivery period upon P.O. confiramtion and 50% cash or check deposit of the total amount product purchase and 50% full cash payment upon delivery.
15. For order basis products strickly NO RETURN NO EXCHANGE POLICY.
16. All products purchase is delivery within metro manila areas.
17. For provincial purchase, delivery and logistic fees will be shoulder by the client.
18. Price is subject to change without prior notice.
