Optoma EX-785 5,000 Ansi Lumens
Ad Information
Ad Description
- Custom Installation - Full Lens-Shift & Lens Options
- XGA - Ultra bright 5000 Lumens
- Premium network monitor & control - Crestron Roomview support
- Extensive connectivity - HDMI, DVI, 5BNC, 2 x VGA
means it achieves perfect images in most environments.
Using centre lens design, full lens shift and interchangeable lens options, the flexible and powerful EX785 is a truly versatile installation solution.
its true brilliance must be experienced. Meeting the highest standards of installation projectors, the EX785 creates
seamless, smooth and radiantly bright corporate presentations, videos and movies.
† 3D Technology
Using the inherent speed of DLP technology, The Optoma EX785 can output video and images at an astonishing rate of 120Hz, allowing you to show full screen, full colour, stereoscopic 3D. The 3D effect is generated by splitting this signal into two standard video streams, one for each eye. Using DLP® Link™ technology, the 3D glasses synchronise with the image on screen to filter each stream to the correct eye. Your brain then combines the two streams to make them jump into life.
The 3D features of the EX785 can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling software. Currently the EX785 does not support 3D TV broadcast systems, SKY in the UK or 3D Blu-ray, though support for these applications may be added in future using additional hardware.
Lens Shift
Lens
Optional Lenses
Easily attached short and long throw lenses give you the option to install the EX785 in different sized locations.
The short throw lens with a throw ratio of 0.8:1 is ideal for rear-projection installations.
The STD throw lens with a throw ratio of 1.6 – 2.0:1 is ideal for standard installations
The long throw lens with a throw ratio of 2.0 – 3.0:1 is ideal for large conference rooms, auditoriums and any other large venue.
Extensive Connectivity
This native XGA projector accepts a wide variety of computer and video input signals. Connectivity includes: 5BNC, HDMI, DVI-D, Component Video, dual VGA (with SCART and YPbPr support), S-Video and Composite.
Five audio inputs for individual PC and video connections enable the EX785 to function as an audio switcher and volume controller, thereby eliminating complicated and costly additional audio hardware and cabling.
Crestron RoomView® - NETWORK CONTROL
Download Crestron RoomView® Express software from:www.crestron.com/getroomview
- Manage up to 250 projectors at the same time (via master PC).
- Control and alter the projector settings using a simple web browser page, including OSD menu control.
- Set up email alerts for warning messages.
- Ideal for large installations in both in the educational and business environments.
EX785 Specification
| Display Technology | Single 0.7” XGA DMD chip DLP® Technology by Texas Instruments | ||||||||||||
| Native Resolution | XGA 1024 x 768 | ||||||||||||
| Brightness - BRIGHT mode1 | 5000 ANSI Lumens | ||||||||||||
| Contrast | 2000:1 | ||||||||||||
| Noise Level | 30/32dB (STD/BRIGHT mode) | ||||||||||||
| Weight | 8.6 kg (without lens) | ||||||||||||
| I/O Connectors |
|
||||||||||||
| Preset Mode |
|
||||||||||||
| Maximum Resolution | UXGA 1600 x 1200 | ||||||||||||
| Computer Compatibility | UXGA, SXGA, XGA, SVGA, VGA, Mac | ||||||||||||
| Video Compatibility | PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p) | ||||||||||||
| Displayable Colours | 134.2 Million | ||||||||||||
| Projection Lens | 3 Optional lenses: Short, STD & Long | ||||||||||||
| Throw Ratio | Short Throw Lens: 0.8:1, STD Lens: 1.6 ~ 2.0:1, Long Throw Lens: 2.0 ~ 3.0:1 | ||||||||||||
| Projection Screen Size | Short Throw Lens: 0.78-4.69m, Standard Lens:1.47 - 5.47m, Long Throw Lens: 1.25 - 12.51m | ||||||||||||
| Projection Distance | Short: 0.5 ~ 3m, STD: 1.5 ~ 7m, Long 3: 2.0 ~ 20m | ||||||||||||
| Horizontal Scan Rate | 15 - 91.1kHz | ||||||||||||
| Vertical Scan Rate | 50 - 85Hz | ||||||||||||
| Lamp Type/Lamp Life2 | 330W, 2000/1500 hours (STD/BRIGHT mode) | ||||||||||||
| Keystone Correction | ± 30° Vertical | ||||||||||||
| Audio | 2 x 5W | ||||||||||||
| Dimensions (W x D x H) | 430 x 340 x 181 mm (inc. feet), 430 x 340 x 164 mm (excl. feet) | ||||||||||||
| Remote Control | Full function remote with laser pointer, mouse control and direct source selecting | ||||||||||||
| Power Supply | 100-240V, 50-60Hz | ||||||||||||
| Power Consumption | 430W BRIGHT mode < 1W Standby mode 390W STD mode < 1W Standby mode | ||||||||||||
| Operating Conditions | 5°C - 35°C, Max. Humidity 80%, Max. Altitude 3000m | ||||||||||||
| Uniformity | 85% | ||||||||||||
| Security | Kensington Lock, Password Protection | ||||||||||||
| Standard Accessories | AC Power Cord, VGA Cable, full Function Remote, Batteries x 2, Lens cover, Quick Start Guide, CD User Manual, Warranty Card, WEEE Card | ||||||||||||
| Optional Accessories | Short Throw Lens, STD Throw Lens, Long Throw Lens, SCART to VGA adaptor, Component to VGA adaptor | ||||||||||||
| RoHS | Compliant | ||||||||||||
| Lens Shift | -15 to +60% Vertical, ±10% Horizontal Before installation please read install guide | ||||||||||||
| 3D Support | 120Hz frame sequential 3D for resolutions up to 720p 60Hz field sequential 3D for resolutions up to 480i |
||||||||||||
| 3D Viewing | Requires Optoma DLP® Link™ active shutter glasses – sold separately |
||||||||||||
| 3D Compatibility | The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling systems. Support for 3D TV broadcast systems, (SKY in the UK) 3D games from a PS3™ & Blu-ray 3D™ will require the Optoma 3D-XL that is available separately. |
 |
 |
 |
 |
 |
 |
 |
1Brightness and lamp lifetime will vary depending on selected projector mode, environmental conditions and usage. As is common with all lamp based projectors, brightness will decrease over the lamp lifetime.
2Typical lamp life achieved through testing. Will vary according to operational use and environmental conditions.
OPTIONAL LENS
- STANDARD LENS - P15,000.00
- SHORT THROW LENS - P40,000.00
- LONG THROW LENS - P28,000.00
WARRANTY
- 2 YEARS UNIT WARRANTY. EXCEPT FOR GLASS PARTS.
- 2 YERAS LABOR WARRANTY.
- 500 HOURS / 6 MONTHS WHICH EVER COMES FIRST FOR LAMP WARRANTY.
- UNIT + WITH STANDARD LENS - P106,500.00
- UNIT + WITH SHORT THROW LENS - P130,500.00
- UNIT + WITH LONG THROW LENS - P118,500.00
TERMS AND CONDITIONS (PLEASE READ CAREFULLY)
- Fax or email purchse order (P.O.) and attention to Mr. Adalid with your signature.
- No P.O. no purchase policy.
- Cash on delivery (C.O.D.).
- Check payment accepted. Delivery after 3 banking days clearing (excluding holiday and weekends).
- For cash and check deposit payment please fax your deposit slip together with your confirmed P.O.
- For cash and check deposit payments and down payments please call for bank details
- Upon P.O. confirmation payment deposit. We will fax or email your copy of Official Invocie and O.R.
- We don't accept credit cards.
- We don't offer terms.
- If stock is available in our office delivery immediately upon P.O. confirmation.
- If stock is not available in our office next day delivery.
- For same day delivery P.O. confirmation cut off time is 11am.
- For next day delivery P.O. confirmation cut off time is 2pm.
- For products that are order basis 35-45 days delivery period upon P.O. confiramtion and 50% cash or check deposit of the total amount product purchase and 50% full cash payment upon delivery.
- For order basis products strickly NO RETURN NO EXCHANGE POLICY.
- All products purchase is delivery within metro manila areas.
- For provincial purchase, delivery and logistic fees will be shoulder by the client.
- Price is subject to change without prior notice.
