Motion Detector Switch Type-2

P750.00

This product is a new type of energy-saving lighting switch, it adopts high sensitivity detector, integrated circuit and SMT.
It has wide detection range and it can identify day and night automatically.

Specification :
Power source : 220-240V AC
Detection angle : 180°
Detection distance : 12±2m
Power frequency : 50Hz
Ambient light : 3-2000LUX(adjustable)
Rated load : 1200W (Resistive load like incandescent lamp)
300W (inductive load such as LED, energy saving lamp )
Working temperature : -20~+40?
Time-delay : min : 10sec ± 3sec
Max : 8min ± 2min
Power consumption : 0.45W (work)
0.1W (static)
Working humidity : <93%RH
Installation height : 1.8m-2.5m
Detection motion speed : 0.6-1.5m/s
IP Grade : IP44(Suitable for indoor and outdoor)
Color : Black, White

Features :
Adopts the most advanced infrared human induction and optical technology.
Energy-saving and high sensitivity.
Automatic, convenient, safe, energy-saving and practical.
Can identify day and night automatically.
Easy to install.

When selecting the mounting position take into account the following points.
1. The sensor is designed for optimum performance when mounted 2.5 meter above ground level.

Avoid installing:
Close to trees or shrubs, which may cause false triggering during wet and windy weather
Close to heat sources such as heat extraction units
Strong electromagnetic disturbance


Package include:
1 x Motion Detector Switch Type-2
(Comes with fixing screws and instructions)
