Mettler Toledo - SG23-ELK - pH/Conductivity/ORP/Redox Meter

SevenGo Duo™ combines user-friendliness, quality and reliable measurements. The meter is designed so that a single keystroke triggers a calibration or measurement or allows accessing stored results or system settings. The kit versions are also well suited for outdoor use or use in the production area because both the meter and the sensors are watertight (IP67).

The revolutionary intelligent sensor management system (ISM®) offers the user an even greater level of security. The calibration data is stored on the chip in the sensor and is used automatically when the sensor is connected to the meter. This ensures that the meter always uses the latest calibration data.

Portable dual-channel meter for the determination of pH, mV, conductivity, TDS (total dissolved solids), salinity and specific resistance
3-point pH calibration with selection from 4 predefined and one user-defined buffer groups
Data memory for 99 GLP data records
Intelligent sensor management (ISM®)
Outstanding operation due to high-contrast display with large figures
Reproducible results due to automatic end point detection, automatic buffer detection and temperature compensation
Rugged watertight housing (IP67)
SG23-ELK Electrode Kit includes: meter, InLab® Expert Pro-ISM and InLab® 738-ISM (both IP67, 2 m cable) and 2-electrode clip
ORP/Redox application requires separate ORP/Redox Electrode, not included with meters & kits

Specifications:

Mettler Toledo - SG23-ELK
pH-range	0.00 ... 14.00
pH-resolution	0.01
pH-relative accuracy	±0.01
mV-range	-1999 ... 1999
mV-resolution	1
mV-relative accuracy	±1
Temperature range °C	pH/mV: -5.0 ... 105/LF: -5.0 ... 105.0
Temperature resolution °C	pH/mV: 0.1/LF: 0.1
Temperature accuracy °C	pH/mV: ±0.5/LF: ±0.2
Calibration	Max. 3 points, 4 predefined buffer groups
Free disk space	99 data records
Display	LCD
Power supply	4 AA batteries 1.5 V or NiMH accumulator 1.3 V
Operating environment	0 ... 40°C; 5 ... 85% relative humidity (no cond.)
Conductivity range	0.10 µS/cm ... 500 mS/cm
Cond. accuracy	± 0.5% maximum value in subrange
Cond. resolution	0.01 ... 1
TDS range	0.1 mg/L ... 300 g/L
Salinity range	0.00 ... 80.00 ppt
TDS resolution	0.01 ... 1
TDS accuracy	±0.5% maximum value in subrange
Resistivity range	0.00 ... 100.00 MOhm*cm
Electrode Supplied	InLab Expert Pro-ISM and InLab 738 ISM
