CCTV Surveillance 4Ch. DVR ,H.264, Remote View, EseeNet, 2012 Series
(Sony/Sharp/420TVL/520TVL/540TVL/600TVL/3.6mm/6mm/IR/led/NightVision/High resolution/IPcam/remoteview/android/ipad/iphone/blackberry /Motion Detection/ Sensor/ H.264/D1)

Feature

Support OEM UI
Support digitazoom function
DDNS settup is needless, Support E-seenet.com &dvrskype.com , DDNS to remote viewing, remote access view, playback, standalone digital video recorder setup, back-up video files & record via IE is available
Support IMAC,IOS,Windows,Android ,Chrome,Safari,Firefox.IE 6789.ect
PowerfuCMS operation, support monitoring up to 64ch at most, no limitation of users
Support photo capture in CMS
Support iphone, android, blackberry, symbain, 4ch viewing at the same time is available for iphone and Android
Software logo and modeNO. can be changed easily by yourself
D1, HD1, CIF,QCIF video recording/playback resolution adjustable
Anti-lightnning and anti-static
HEXAPLEX operation Record, Live view, Playback, Backup, Network Contro& Mobile Phone



Specification





Model


4 standalone dvr china




Operation system


Embedded Linux operation system




System resource


4Channel CIF/ D1 real-time video and network-wide transmission,
4Channel CIF/ D1 Playback at the same time




Operation interface


Graphical user interface (GUI), mouse,front button, remote control operation




Video standard


PAL;NTSC




Image compression


H.264




Audio compression


ADPCM




Recoding mode


Manual, timing, alarm, motion detection




Video Search


Time search, event search, channel search, log search




Backup


Network Backup, USB Backup, HDD Backup




Video input


4BNC




Video output


1BNC,1VGA




Audio input


2Channel




Audio output


1Channel




Monitoring quality


PAL:720x576(D1) NTSC:720x480(D1)




Playback quality


PAL:352x288(CIF) NTSC:352x240(CIF)




Motion Detection


Each Channel of the detection area (16 16), multi-level sensitivity can be set




Image display


1,4 Image display




Video Speed


PAL: 25 frames / sec (adjustable) NTSC: 30 frames / sec (adjustable)




Video Save


Hard drive, Network




Local playback


1-4 Channel CIF / D1




Alarm Input


4Channel (optional)




Alarm Output


1Channel (optional)




PTZ


RS485




HardDisk Interface


1 SATA, up to 2000G




Network interface


RJ45 10M/100M self-adaptive Ethernet




USB Interface


2USB2.0 for mouse and file backup/ upgrade




Power supply


12V, 3A





Warranty:
6 Months on DVR, 1 Month on Accessories.
