The EnGenius ENS200 is a high-performance, cost-effective 802.11n 2.4GHz Wireless Outdoor Bridge/AP with speeds up to 150Mbps. This Bridge/AP features up to 400mW transmit power for longer range building-to-building wireless bridge connections or for Wireless ISP deployments as a CPE (Customer Premise Equipment) solution.

The ENS200 can be configured to work in a variety of operation modes – as an Access Point, WDS (Wireless Distribution System) AP, WDS station, as well as a WDS bridge. The multiple operation modes of the ENS200 make it a versatile solution for creating a high-speed, stable and secure outdoor wireless link between buildings; for offering wireless access to a hosted Internet connection in a retirement home community or an RV park; or for users in RV parks, campgrounds and marinas to access an available public Wi-Fi hotspot.

ENS200 also includes a robust set of security features including WPA/WPA2 Personal and Enterprise encryption, 802.1x RADIUS authentication, hidden SSID and MAC address filtering.



• High 400mW Transmit Power Delivers Long-Range Coverage

o Offers superior wireless network coverage over other brands

o Perfect for Point-to-Point wireless links



• Up to 150Mbps Wireless Speed and Backward Compatible to 802.11b/g

o In Wireless-N mode, maximum data rate reaches up to 150 Mbps when connected to another Wireless-N device

o Complies with IEEE802.11b/g/n standards



• Built-in Dual Polarity Antenna Maximizes Wireless Connectivity

o Built-in directional antenna

o Dual polarity design allows adjustment to the environment



• Designed for Outdoor Environments

o IP65 waterproof housing and UV coating for prolonged exposure to sunlight



• PoE Kit & Mast Strap Included

o PoE (Power-over-Ethernet) kit includes PoE injector and power adapter

o Mast strap



Hardware Specification



MCU AR7240

RF AR9285

Memory 32MB

Flash 8MB

Physical Interface 2 x RJ-45 port for 10/100 Ethernet

Reset Button in PoE Injector (EPE1212)



Power Requirements

-Active Ethernet (Power over Ethernet)

- Proprietary PoE design

- Power Adapter 12V/1A



Built-in Antenna

- 2.4GHz

- 8dBi gain

- Beam width
Horizontal : 60^o

Vertical : 60^o



RF Specification



Standard IEEE 802.11 b/g/n

Frequency Band 802.11b/g/n 2.412 to 2.472 GHz,

Data rate Up to 150 Mbps

Receive Sensitivity (Typical) 802.11n (2.4GHz)

-95/-92/-87/-85dBm @ MCS0~MCS3

-80/-78 @ MCS4/MCS5

-78/-73dBm @ MCS6/MCS7



802.11g

-96/-92/-89/-85/-82dBm

@ 6/9/12/18/24Mbps

-80dBm @ 36Mbps

-75dBm @ 54Mbs



802.11b

-95/-93dBm @ 1/2Mbps

-92/-89dBm @ 5.5/11Mbps



Available transmit power



802.11n (2.4GHz) ( ± 2dBm )

26dBm @ MCS0~3

25/24dBm @ MCS4/MCS5

22/21dBm @ MCS6/MCS7



802.11g( ± 2dBm )

26dBm @

6/9/12/18/24Mbps

25dBm @ 36Mbps

23dBm @ 48Mbps

22dBm @ 54Mbps



Software Specification



Operation Mode Client Bridge / Client Router / WDS Bridge / WDS Station/ Access Point

Wireless - WiFi Scheduling

- Signal Strength Display

- RSSI Indicator

- BSSID/Preferred SSID

- Client Bridge / Client Router / WDS Bridge / WDS Station



Security - WEP Encryption-64/128/152 bit

- WPA/WPA2 Personal (WPA-PSK using TKIP or AES) for CR/CB mode only

- WPA/WPA2 Enterprise (WPA-EAP using TKIP) for CR/CB mode only

- Emergency Recovery Page



Management



Administrator Setting Administrator password can be changed

QoS WMM, Traffic Shaping

Reset Setting Reset to factory default and reboot

MIB MIB I , MIB II and Private MIB

Auto Reboot Automatically reboot/restart at scheduled time

Display Time Show NTP, Manual setting for Time server and Synchronize with PC

SNMP V1 , V2C, V3

Backup Save all settings via Web interface

Environment &

Environment & Mechanical



Temperature Range Operating -4°F~158°F

Storage -22°F~176°F

Humidity (non-condensing) 0%?90% typical

Waterproof IP65





• ENS200 outdoor long range Access Point
• PoE Injector
• 12v AC-DC Power Adapter
• CD with User’s Manual
• Mast mount strap
• Special screw set
