Hose size: 3~51mm or 1/8" to 2" (up to 4-wire)
Max opening (mm): 120 mm
Openning dies time:1s
Close dies time:2-3s
Crimping dies time:4s
Master die D/L (mm) is 65/80mm/90mm( or customize)
Rated pressure: 31.5mpa
voltage:380V/220V/415V/230V or customize
The largest crimping pressure: 500T
Rular precision: 0.02 mm
Oil pump out-let quantity: 2.5ml 5ml 10ml/rad (piston pumps);
Noise level:65dB
Protection class: IP54
Dimension: 670(L)×490(W)×780(H)mm
Weight: 250 kg
Tank: 50L
Dies: 11sets(or customize)
Piston, Cylinder, All Dies & Parent Jaws are wire cut after hardening and grinding
This machine main feature is its production capacity that will make this machine leader in his class automatic
