ENGINE

ENGINE TYPE: 4-STROKE, SINGLE CYLINDER, AIR - COOLED

VALVE SYSTEM: SOHC, 2 valve

BORE X STROKE: 51.0 mm x 55.2 mm

DISPLACEMENT: 112.7

MAXIMUM HORSE POWER: 6.9kw/8800rpm

MAXIMUM TORQUE: 8.7N-m/6500rpm

FUEL SYSTEM: CARBURETOR (BS22)

COMPRESSION RATIO: 9.4

IGNITION SYSTEM: CDI

STARTER SYSTEM: ELECTRIC AND KICK

TRANSMISSION: CVT/V-BELT

SUSPENSION

FRONT: TELESCOPIC, COIL SPRING, OIL DAMPED

REAR: SWINGARM TYPE, COIL SPRING, OIL DAMPED

TIRES

FRONT: 70/90 - 14M/C 34P

REAR: 80/90 - 14M/C 46P

BRAKES/SIZES

FRONT: DISC

REAR: DRUM

WHEELS: CAST

OTHERS

BATTERY: MF

HEADLIGHT (WATTAGE): 12V 32W/32WX1

OVERALL LENGTH: 1,850 mm

OVERALL WIDTH: 665 mm

OVERALL HEIGHT: 1,035 mm

WHEEL BASE: 1,235 mm

GROUND CLEARANCE: 135 mm

SEAT HEIGHT: 735 mm

CURB MASS: 87 kg

UNDER SEAT COMPARTMENT: 4.5
