Compression Ratio

9.5 :1

a) Maximum power: 5.8 kW {7.9 PS} @ 8,000 rpm

b) Maximum torque: 8.1 N·m {0.82 kgf·m} @ 6,000 rpm

Fuel System: Carburetor KEIHIN PB18

Starting

Kick

Ignition

Battery and coil (transistorized)

Lubrication

Forced lubrication (wet sump)

DRIVERAIN

Transmission

4-speed, Constant mesh, Return shift

Gear ratios

1st: 3.000 (36/12)

2nd: 1.937 (31/16)

3rd: 1.350 (27/20)

4th: 1.086 (25/23)

Final reduction ratio

2.066 (31/15)

Clutch

Centrifugal and wet multi disc

Frame Type

Tube backbone Caster (rake) 26º

TYRE

a) front 100/90-12 49J Tubeless

b) rear 100/90-12 49J Tubeless

Suspension

Front Type:Telescopic fork (upside-down)

Rear Type: Swingarm

BRAKES

Front Type: Single disc

Rear Type: Single disc

DIMENSIONS

Overall length: 1,670 mm

Overall width: 705 mm

Overall height: 995 mm

wheelbase: 1,165 mm

Ground clearance: 225 mm

Curb mass: 85 kg

Fuel capacity: 7.3 liters

Seat height: 750 mm
